Processor |
Intel® Celeron Intel Core i5 4200U(1.6 GHz) |
System Memory |
4GB Standard, DDR3L 1333MHz |
Storage Device |
HDD 500Gb SATA |
OS Supported |
Windows 7, Windows 8, Windows 10 IoT Enterprise, POS Ready 7, Linux |
Audio |
Realtek ALC662 |
Display and Touch
Types |
15”TFT LCD, LED Backlight |
Resolution |
1024*768 |
Touch Screen |
Five-wire analog resistive or projected capacitive |
Customer Display |
LED (8C digital tube) |
External I/O Ports
VGA |
1*DB-15 |
USB |
5*USB2.0, 1*USB3.0 |
COM |
5 |
LAN |
1*RJ45 |
Audio |
1*line-out |
Cash Drawer |
1 |
Power
Power Supply |
Adaptor 12V DC 5A |
Physical Environmental
Operating Temperature |
0°C °C at 20%-80% humidity |
Storage Temperature |
– 20°C °C at 20%-80% humidity |
Dimensions (L*W*H) |
347*372*402mm |
Packing Dimensions |
450*420*480mm |
Net Weight |
6.10kg |
Packing Weight |
8.21kg |
|
CE FCC |
Options & Peripherals
Second Display |
10”&15” TFT LCD |
Customer Display (VFD) |
VFD (2*20 lines) |
MSR |
3 tracks |
Fingerprint |
Built-in fingerprint reader |
